Description
A concept particularly suited to long paired alleys.
Possibility of curved scraping at 22,5° - 45° - 67,5° - 90°.
Easy installation in existing buildings.
Traction torque management for optimum efficiency combined with increased safety for livestock. User-friendly and functional 3ème generation control cabinet, frost-protection functions, timed discharge as standard.
Chain tensioning ensuring optimum durability of the installation.
Scraper shapes adapted to the different types of buildings and bedding.
Possibility of scraping alleys of different lengths.
Technical specifications
Drive unit - Working capacity for lengths beyond 100 m.
Management of 3 rows with one central unit Control cabinet - Programming of scraping frequency and times
Timed discharge
Motor torque management for animal safety
Scraping shoes - Straight scraper: for slurry or low-straw manure
V-scraper: for straw-rich manure
Inverted V-scraper: for scraping as close as possible to the discharge point
Chain - MIRO square chain with forged riveted links, black or galvanised, or marine chain 14,50
Technical specifications
| Category | Farm infrastructure |
|---|---|
| Subcategory | Waste management |
